Запросить цитату Файлы скачатьTable Type 5kN 10kN 20kN computer control Electronic Universal Testing Machine with pneumatic side wedge grip
1.Application
It is applicable for wide range of material for tensiontest, compressiontest, bending, shearing and low cycle test. Suitable for metal, rubber, plastic, spring, textile, and components testing. It is widely used in the corresponding industries, research and development, test institutes and training centers etc.
2.Standards
ASTMA370,ASTME4,ASTME8,ASTME9,ISO6892,ISO7438,ISO7500-1,EN10002-4,GB/T228-2002,GB 16491-2008, HGT 3844-2008 QBT 11130-1991, GB13-22-1991, HGT 3849-2008,GB6349-1986, GB/T 1040.2-2006, ASTM C165, EN826, EN1606, EN1607, EN12430 etc.
3.Specifications
Model HST WDW-5E HST WDW-10 HST WDW-20 HST WDW-30 HST WDW-50E Max. Load(kN) 5 10 20 30 50 Load accuracy Class 0.5 Load range 0.2%~100%F·S Load resolution 1/500000 Resolution of deformation(um) 0.04 Accuracy of displacement Within±0.5%of indicating load Resolution of displacement 0.01mm Test speed(mm/min) 0.05-1000 stepless arbitrary setting Speed accuracy within ±1% / ±0.5% of set speed E-Tensile space(mm) 670 670 670 770 770 E-Compression space(mm) 900 900 900 1000 1000 D-Test width(mm) 450 450 450 550 550 F-Beam travel distance(mm) 1000 1000 1000 1100 1100 Power supply AC220V±10%,50Hz/60Hz (can be customized) Video show
